| INPUT |
|
VOLTAGE (V) |
|
AC90∼132V/180∼264 1Ø / 5.5A/3.5A typ (Io=100%) |
|
|
| |
CURRENT |
|
내용없슴 |
|
|
| |
FREQUENCY |
|
50 / 60Hz (47 ∼ 440Hz) |
|
|
| |
EFFICIENCY |
|
78 % min |
|
|
| |
INRUSH CURRENT |
|
30A typ(AC IN 110V, Io=100%) 60A typ(AC IN 220, Io=100%) |
|
| OUTPUT |
|
VOLTAGE (V) |
|
12 |
|
|
| |
CURRENT (A) |
|
25.0 |
|
|
| |
REGULATION,
LINE (mV) |
|
60 Max |
|
|
| |
REGULATION,
LOAD(mV) |
|
120 Max |
|
|
| |
RIPPLE (mVP-P) |
|
120 Max |
|
|
| |
RIPPLE, NOISE
(mVP-P) |
|
170 Max |
|
|
| |
TEMPERATURE
DRIFT 0∼+50℃(mV) |
|
120 Max |
|
|
| |
RISE TIME(mS) |
|
500 Max (AC IN 90V/180V Io=100%) |
|
|
| |
HOLDING TIME(mS) |
|
20 typ (AC IN 90V/180V Io=100%) |
|
|
| |
OUTPUT VOLTAGE SETTING(V) |
|
내용없슴 |
|
|
| |
POWER UP TIME(mS) |
|
|
|
|
| |
HOLD UP TIME(mS) |
|
|
|
PROTECTION
CIRCUIT |
|
OVER CURRENT
PROTECTION
|
|
Works at over 110% of rating and recovers automatically |
|
|
| |
OVER VOLTAGE
PROTECTION |
|
Works at 115∼140% of rating |
|
ELECTRICALLY
ISOLATED
|
|
INPUT-OUTPUT
|
|
AC 1,500V 1 minute, DC 500V 100㏁ (At Room Temperature ＆ Humidity) |
|
|
| |
INPUT-CASE·FG
|
|
AC 1,500V 1 minute, DC 500V 100㏁ (At Room Temperature ＆ Humidity) |
|
|
| |
OUTPUT-CASE |
|
AC 500V 1 minute, DC 500V 100㏁ (At Room Temperature ＆ Humidity) |
|
|
| |
INPUT-FG |
|
내용없슴 |
|
|
| |
OUTPUT-FG |
|
내용없슴 |
|
|
| |
HIGH POT |
|
내용없슴 |
|
|
| |
ISOLATION |
|
내용없슴 |
|
ENVIRONMENT
|
|
OPERATING TEMP
AND HUMID |
|
-10 ~ +50℃ , 20 ~ 90% RH(Non Condensing) |
|
|
| |
STORAGE TEMP
AND HUMID |
|
-20 ~ +75℃ , 20 ~ 90% RH(Non Condensing) |
|
|
| |
VIBRATION
|
|
10 ~ 55Hz at 1G 3 minutes periods, 30 minutes along X, Y and Z axis |
|
|
| |
IMPACT
|
|
10G for 20mS, Once on each X, Y and Z axis |
|
| SAFETY |
|
SAFETY
REGULATION
|
|
내용없슴 |
|
|
| |
LINE CONDUCTED
RF VOLTAGE
|
|
내용없슴 |
