Basic specifications |
| DC Voltage range |
400.0 mV to 1000 V, 5 ranges, Best accuracy: ±0.6 % rdg. ±2 dgt. |
| AC Voltage range |
400.0 mV to 1000 V, 5 ranges, Best accuracy: ±2.0 % rdg. ±2 dgt. , Average rectifier effective value |
Frequency characteristics
at AC Voltage |
40 to 500 Hz |
| Resistance range |
400.0 ohm to 40.00 M-ohm, 6 ranges, Best accuracy: ±0.6 % rdg. ±3 dgt. |
| DC Current range |
400.0 µA to 10.00 A, 5 ranges, Best accuracy: ±1.5 % rdg. ±2 dgt. |
| AC Current range |
400.0 µA to 10.00 A, 5 ranges, Best accuracy: ±2.0 % rdg. ±2 dgt. , Average rectifier effective value |
Frequency characteristics
at AC Current |
40 to 500 Hz |
| Frequency range |
None |
| Continuity |
Possible, 34.5 ohm or less (at 400 ohm range) |
| Diode check |
Possible (3.3 V open terminal voltage) |
| Other functions |
RS-232C, Data hold |
| Auto power save |
Possible (Cancel possible) |
| Range switching |
Auto or Manual |
| Display |
LCD, max. 4000 dgt. , Bar graph display: Maximum 41 dots |
| Sampling rate |
2.5 times/sec, 13 times/sec (Bar graph) |
| Power supply |
6F22(006P) × 1 dry battery, (Continuous use 200 hours) |
| Dimensions, mass |
76 mm(2.99 in)W × 167 mm(6.57 in)H × 33 mm(1.30 in)D, 400 g (14.2 oz) |
| Accessories |
3851-10 TEST LEAD (1), Holster (1) | |
|
|
|
|
|
|
|
|
| |
|
